Connect to Exchange Online PowerShell Using MFA (Multi Factor Authentication)

If you want to connect Exchange Online PowerShell using MFA, you need to use a special PowerShell tool offered by Microsoft “Exchange Online PowerShell Module” (EXO).

You can install Exchange Online PowerShell Module (EXO V1) manually or you can use dedicated script that install the module and connects Exchange Online PowerShell using MFA. Let’s check both methods in detail.

• Automated Method:
  • PowerShell script to connect Exchange Online PowerShell with MFA
• Manual Method:
  • Step1: Install Exchange Online PowerShell Module for MFA(One time process)
  • Step2: Connect Exchange Online PowerShell using MFA enabled Account

To ease your work, we have documented common troubleshooting tips at the bottom.

Unfortunately, connecting Exchange Online PowerShell using MFA is somewhat tricky, so newbies can get lost quickly. No worries! We are here to help admins. We have written a user-friendly PowerShell script to connect Exchange Online PowerShell with MFA which does following things.

• Downloads Exchange Online Remote PowerShell Module
• Installs Exchange Online PowerShell Module
• Connects Exchange Online PowerShell using MFA

Download Script: ConnectExchangeOnlinePowerShell.ps1

The first thing you need to do is download the Exchange Online Remote PowerShell module.To download Exchange Online PowerShell Module directly, you can use this quick link: https://cmdletpswmodule.blob.core.windows.net/exopsmodule/Microsoft.Online.CSE.PSModule.Client.application

Alternatively, to download the Exchange Online MFA module through Microsoft, follow the below steps.

1.Login to Exchange Admin Center using Internet Explorer or Edge.

2.In the EAC, go to Hybrid and click the Configure button (as mentioned in below image) to download the Exchange Online PowerShell Module for MFA.

Note: A browser that uses ClickOnce to download (like IE or Edge) is needed to download otherwise you will get an error during installation. Click Connect-ExoPSSession troubleshooting tips for more troubleshooting tips.

3.Click Install.

1.Connect-EXOPSSession used to connect to Exchange Online with MFA. You can’t use Connect-EXOPSSession in standard Windows PowerShell. You need to launch Exchange Online Remote PowerShell module. When you launch the Exchange Online Remote PowerShell module, a tip about the usage is shown.

2.Connect-EXOPSSession has a parameter UserPrincipalName. You can use Connect-EXOPSSession, with or without UserPrincipalName. For eg,

3.Enter the password in the sign-in window and then click Sign in.

4. A verification code generated and delivered based on MFA configured for your account. Enter the verification code in the verification window and then click Sign in.

5. After step 4, the Exchange online cmdlets are imported into Exchange Online remote PowerShell Module session. If you don’t receive any errors, you connected successfully as shown in the below figure.

If you want to connect all Office 365 Services PowerShell with a single cmdlet, please refer: Connect to all Office 365 Services using PowerShell (Supports MFA too)

Most people encounters numerous challenges when they try to use Connect-EXOPSSession cmdlet. To ensure hassle-free installation and execution, we have documented the common errors and their troubleshooting tips in this blog. If you want to get a list of MFA enabled users in your tenant, you can refer Export Office 365 users’ MFA status report.

1.You can’t use Standard Windows PowerShell to Connect Exchange Online With MFA:

If you use standard Windows PowerShell to connect Exchange Online using MFA enabled account, you will get the following error. 

New-PSSession : outlook.office365. com Connecting to remote server outlook.office365. com failed with the following error message : Access is denied. For more information, see the about_Remote_Troubleshooting Help topic.+ $Session = New-PSSession -ConfigurationName Microsoft.Exchange -Conne ...
+ FullyQualifiedErrorId : AccessDenied,PSSessionOpenFailed


Import-PSSession : Cannot validate argument on parameter 'Session'. The argument is null. Provide a valid value for the argument, and then try running the command again. + Import-PSSession $Session -CommandName Get-Mailbox,Get-MailboxPermi ...
+ FullyQualifiedErrorId : ParameterArgumentValidationError,Microsoft.PowerShell.Commands. ImportPSSessionCommand

If you want to connect Exchange Online PowerShell with MFA, you need to install “Exchange Online PowerShell Module” (EXO).

2.How to Import MFA Enabled Exchange Online Powershell Module in ISE?

Instead of using Exchange Online PowerShell console, you can import Exchange Online PowerShell module in Windows PowerShell ISE. To successfully use the Connect-EXOPPSSession cmdlet in the ISE, you need to run the below code in ISE.

Now, you can use PowerShell ISE to Connect Exchange Online with MFA.

Note: Before using these code, you should install Exchange Remote Online PowerShell module.

3.Unable to Install Exchange Online PowerShell Module- Cannot start application:

If you didn’t use IE or Edge to download Exchange Online PowerShell Module, you will face error during installation.

4.Enable basic authentication on the WinRM Service:

Windows Remote Management (WinRM) needs to allow basic authentication (It is enabled by default) to create ExoPSSession. If basic authentication is disabled, you’ll get below error when you try to connect:

Note: The Basic authentication header is required to transport the session’s OAuth token, since the client-side WinRM implementation has no support for OAuth.

To check whether the basic authentication is enabled, run below command in command prompt.

If Basic= true not set, you need to run below command to enable basic authentication.

After executing above command, the output looks similar to below screenshot.

Note: You can also use EXO V2 module to connect Exchange Online PowerShell with modern auth. Even though the EXO V2 module uses modern auth, it still needs WinRM basic auth to transport modern auth tokens. To improve the security, Microsoft recently introduced EXO V2 Preview module 2.0.6. It allows admin to use EXO V2 module without WinRM basic authentication.

5.Start WinRM service:

In order to enable basic authentication in WinRM, WinRM service must be in running state. Otherwise, you will get following error: The client cannot connect to the destination specified in the request. Verify that the service on the destination is running and is accepting requests. Consult the logs and documentation for the WS-Management service running on the destination, most commonly IIS or WinRM.

To start WinRM service, launch command prompt as administrator and run following command

When the cmd prompt displays Make these changes [y/n]?, type y.

If configuration is successful, WinRM service started output will be displayed.

6.Where do I find the Exchange Online Remote PowerShell Module?

You won’t be able to find the Exchange Online Remote PowerShell module, using the Get-Module cmdlet. When you install ClickOnce application, it will be installed in the below directory.

%UserProfile%\AppData\Local\Apps\2.0

You can use the desktop shortcut, to launch the Exchange Online Remote PowerShell module.

7.Disconnect the remote PowerShell session:

Make sure to disconnect the remote PowerShell session when you’re finished. Else you ended up using all remote PowerShell sessions available to you and you will get the following error.

New-ExoPSSession : Processing data from remote server outlook.office365. com failed with the following error message: [AuthZRequestId=068a9813-8420-43f0-9f20-692228962287] [FailureCategory=AuthZ-AuthorizationException] Fail to create a runspace because you have exceeded the maximum number of connections allowed: 10

To disconnect all PowerShell session in the current window, you can use below command.

With the introduction of security defaults and MFA enforcement, most scripts are broken in scheduled tasks or automation. As a workaround, most admins used conditional access to exclude MFA for the service accounts. It makes the organization less secure. To fix this problem, Microsoft introduced a new Public preview of the EXO V2 module (Version 2.0.3 or later) to connect Exchange Online with an unattended script.
